Linksys SPA400






Linksys SPA400

Linksys SPA400 - Overview
The Linksys SPA400 features the ability to connect up to four (4) standard analog telephones lines to a Linksys Voice System (LVS) VoIP network and includes the additional benefit of an integrated voicemail application. The Linksys SPA400 utilizes multiple analog phone lines and automatically routes calls to and from your existing PSTN telephone service. Designed to be implemented with the LVS IP Telephony System, the SPA400 enables cost-conscience business users to leverage the high value features generally found only on more expensive PBX equipment.

The Linksys SPA400 also includes an integrated voicemail application server supporting up to 32 voicemail accounts or boxes with customized greetings, providing LVS users the ability to receive and playback voicemail messages from their Linksys IP Phones.

The Linksys SPA400 supports four (4) RJ-11 FXO ports to connect to the PSTN and also includes one 10/100 BaseT RJ-45 Ethernet interface that is used to connect to the local IP network. Compact in design, the Linksys SPA400 is perfectly suited for a small business in providing reliable operation for both VoIP and PSTN voice communication service.

Installed by the service provider, reseller, or end user, the Linksys SPA400 enables transparent PSTN gateway functionality for a VoIP telephony network and is a key element in building a solid business communications system.

Linksys SPA400 - Features

* Connects 4 Analog PSTN Lines to your VoIP network
* 4 RJ-11 FXO Ports
* Integrated Voicemail Application Server
* Enables SPA9000 IP Phone Clients to Leave and Playback Voicemail
* USB 1.1 Host Interface for the Voicemail Module and Application
* Configure up to 32 Voicemail Accounts
* Caller ID Detection
* Hunt Grouping of FXO Ports
* Advanced Inbound and Outbound Call Routing
* Independent Configurable Dial Plans to Utilize Multiple Service Providers
* 8 LEDs: Power, Status, LAN, Ports 1-4, USB
* External Switching Power Adapter 5V DC/2A


Specifications

Spa400 Voice Mail With 4fxo For IP PBX Spa9000
Internet Telephony Gateway with 4 FXO Ports
Advanced Multi-Port PSTN Gateway S


LINKSYS SPA400

Features
Connects 4 Analog PSTN Lines to your VoIP network
4 RJ-11 FXO Ports
Integrated Voicemail Application Server
Enables SPA9000 IP Phone Clients to Leave and Playback Voicemail
USB 1.1 Host Interface for the Voicemail Module and Application
Configure up to 32 Voicemail Accounts
Caller ID Detection
Hunt Grouping of FXO Ports
Advanced Inbound and Outbound Call Routing
Independent Configurable Dial Plans to Utilize Multiple Service Providers
8 LEDs: Power, Status, LAN, Ports 1-4, USB
External Switching Power Adapter 5V DC/2A

Package Contents
1 - SPA400
1 - Power Adapter
1- USB 1.1 Voicemail Module
1 - RJ45 Ethernet Cable
4 -RJ11 Telephone Cables
1 - Quick Installation Guide


Specifications

Model spa400:
* Note: Many specifications are programmable within a defined range or list
of options. Please see the SPA Administration Guide for details. The target
configuration profile is uploaded to the SPA400 at the time of provisioning.

Standards:
IEEE 802.3 (10BaseT), IEEE 802.3u (1000BaseTX)

Cabling Type:
RJ45 Ethernet Category 5, RJ11 Standard Phone Cable

LEDs:
Power, Status, LAN, Port 1-4, USB

Voice Protocols:
Session Initiation Protocol (SIP v2)

Voice Algorithms:
G.711 a-law and μ-Law G.726, G.729 A B
DTMF: In-band (RFC 2833)
Call Progress Tone Generation
Echo Cancellation (G.168)
Jitter Buffer - Adaptive
VAD - Voice Activity Detection
Call Progress Tone Generation
Comfort Noise Generation
Frame Loss Concealment

Provisioning, Administration & Maintenance:
Web Browser Administration & Configuration via Integral Web Server
Telnet access to command line interface
Automated Provisioning & Upgrade via HTTP
Non-intrusive, In-Service Upgrades
Report Generation & Event Logging
System Fault self-test

Security:
Password Protected System Reset to Factory Default
Password Protected Admin and User Acess Authority

Physical Interfaces:
1 100base T RJ-45 Ethernet Port (IEEE 802.3)
1 USB 1.1

- Garansi 1 thn ( Replacement )
- Gratis Ongkos Kirim ( DEJABOTABEK )
- Harga Rp. 1.850,000,-

Berminat ??
Silahkan kontak sales kami.
YM1: toekang.modem03 ( Johan )
YM2: toekang.modem02 ( Alex )
YM3: toekang.modem ( Hendra )

Telp.021- 32764881
Telp.021- 32764889
Hp.08561741710 ( Johan )
